FEATURES
·FOUR ROLLS WITH INDEPENDENT DRIVE SYSTEMS.
·SINGLE OR DOUBLE STRAND OPERATION.
·DIGITAL AC VARIABLE SPEED DRIVES WITH PLC CONTROL VIA GRAPHIC INTERFACE.
·AUTOMATED SPEED CONTROL.　 DRIVEN CLOTH LIFTER REELS WITH TWIST SENSORS.
·‘O’ RING GUIDES WITH MOTORIZED WIDTH CHANGE AND HOLE DETECTORS.
·DRIVEN FEED ROLLS TO PRESENT FABRIC TO PRE-WET EXTRACT SCRAYS.
·STAINLESS STEEL PRE-WET AND CHEMICAL SCRAYS.
·LIQUID LEVEL CONTROL.
·EDGE DRIVE AFTER SPREADING SYSTEM.
Graphic Interface
BENEFITS

·HIGH PRODUCTIVITY – 80 METERS PER MINUTE.

·LOW TOTAL MOISTURE LEVELS SIGNIFICANTLY INCREASE DRYER PRODUCTIVITY LEVELS. ON COTTON JERSEY
FABRICS OUR ACTUAL FIELD DATA SUPPORTS EXPECTED EXTRACT MOISTURE LEVELS TO BE 58-60% AND PROCESS
MOISTURE LEVELS TO BE 78-80%.

·EVEN CHEMICAL APPLICATION.

·LOW MAINTENANCE REQUIREMENTS WITH DIRECT COUPLED GEAR BOXES, DIRECT MOTOR TO BELT DRIVE SYSTEM
S, AND MINIMAL CHAIN USAGE.
Twin ballloon Features
Twist sensor Ring guide entry Two Padder

over feed system for stitch recovery
